5 - 120M3 LPG Tanker Truck , LPG Bulk Tank For Transport CCC Certified
5 - 120M3 LPG Tanker Truck , LPG Bulk Tank For Transport CCC Certified
Basic Properties
certificate
ASME ISO CCC ISO9001
PRODUCT MODEL
5 ~ 120m3
Trading Properties
MOQ
1 Unit
unit price
Price negotiable
Packing
Nake Package Used RO-RO Ship Container Ship
period for dispatch
15-30 work days
payment method
L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Capacity
50000 units per year
Product Details
Highlight:
lpg tanker truck
,lpg bullet tanks
Product Name:
Liquid Gas Tank
Applications:
LPG Cylinder Refilling LPG Storage Tanker
Color:
Red White LPG Storage Tank Customer's Request
LPG Filling Medium:
Liquefied Petroleum Gas Propane
Tank Capacity:
5m3 10m3 20m3 30m3 40m3 50m3 60m3 80m3 100m3
Level Gauge:
Magnetic Levle Gauge, Floating Ball Gauge, Rochester Gauge
Product Brief
5-120M3 LPG Tanker LPG Bulk Tank LPG Tank Bulk Liquid Gas Tank Part 2. LPG Tank Technical Parameters: Item Unit Parameter Product Name Liquefied Gas Storage Tank Brand Name ChengLiWei Model CLG3200-120 Overall dimensions mm TBD Tank Dimension DN3200*18*13800(inner dia*thickness*length) Fact cubage ...
Product Description
5-120M3 LPG Tanker LPG Bulk Tank LPG Tank Bulk Liquid Gas Tank
Part 2. LPG Tank Technical Parameters:
| Item | Unit | Parameter | ||||
| Product Name | Liquefied Gas Storage Tank | |||||
| Brand Name | ChengLiWei | |||||
| Model | CLG3200-120 | |||||
| Overall dimensions | mm | TBD | ||||
| Tank Dimension | DN3200*18*13800(inner dia*thickness*length) | |||||
| Fact cubage | m3 | 120 | ||||
| Fact loading weight | T | 60 | ||||
| Tank weight | 22.8 | |||||
| Working pressure | Mpa | ≤1.6 | ||||
| Testing hydraulic pressure | 2.12 | |||||
| Testing pressure for gas density | 1.77 | |||||
| Test pressure | 1.69 | |||||
| Air tight test pressure | 1.69 | |||||
| Safety valve popping pressure | 1.68 | |||||
| Working temperature | ºC | ≤50 | ||||
| Other | Tank material: 16MnR,; pressure relief valve model: HG20592-WN, open pressure: 1.68-1.76Mpa; LPG density: 0.42t/m3 . Mark dangerous caution on tank. Pressure pump with connect valve: Import filter valve, inlet cut-off valve, outlet cut-off valve, export check valve | |||||
| color | According to customer's requirement | |||||
| Nominal Diameter | Connect surface | Name | Pipe dimension | extension elongation | ||
| 3" | RF | Liquid inlet | 150 | |||
| 3" | RF | Liquid outlet | 150 | |||
| 3" | RF | gas phase outlet | 150 | |||
| 2" | RF | Air vent | 150 | |||
| 3" | RF | Drain | 150 | |||
| 4" | RF | Level gauge | ||||
| M27*2 | thread | Thermometer | 40 | |||
| M20*1.5 | thread | Pressure gauge | 40 | |||
| 18" | FM | Manhole | 220 | |||
| 4" | RF | Safty valve | 150 | |||
Part 6. LPG Tank Progress:
