Howo 4x2 5 Ton Refrigerated Truck , Refrigerated Delivery Van With Hook

We received your trucks, and are very happy with the quality

—— Grace Arndt

I received the fuel tanker trailers, I am very pleased with the quality. Very good product

—— Hans Boehner

I'm Online Chat Now

Howo 4x2 5 Ton Refrigerated Truck , Refrigerated Delivery Van With Hook

China Howo 4x2 5 Ton Refrigerated Truck , Refrigerated Delivery Van With Hook supplier
Howo 4x2 5 Ton Refrigerated Truck , Refrigerated Delivery Van With Hook supplier Howo 4x2 5 Ton Refrigerated Truck , Refrigerated Delivery Van With Hook supplier

Large Image :  Howo 4x2 5 Ton Refrigerated Truck , Refrigerated Delivery Van With Hook

Product Details:

Certification: ISO CCC ISO9001
Model Number: ZZ1047C3414B145

Payment & Shipping Terms:

Minimum Order Quantity: 1 Unit
Price: Negotiable
Packaging Details: Nake Package Used RO-RO Ship Container Ship
Delivery Time: 15-20 work days
Payment Terms: L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability: 50000 units per year
Contact Now
Detailed Product Description
Product Name: Refrigerated Box Van Freezer Brand: Thermo King, Hanxue, Korea Brand Etc
Applications: Used For Freezer Food, Fruit, Beer, Fish, Vege Color: White Blue Yellow Customer's Requirement
Truck Drive Wheel: 4x2 6x4 8x4 Material Type: 8cm Middle Polyfoam Insulation
Body Material: Strong Fiberglass Inner And Outer Wall Truck Brand: Dongfeng FAW Foton Sinotruk JAC Isuzu
High Light:

refrigerated delivery truck


freezer box truck

Howo Foton 4x2 5Tons Refrigeration Box Truck Fresh Meat Refrigerated Truck With Hook


Refrigerator Trcuk also called ice truck, insulated car, van, explosion-proof cars, refrigerated trucks, refrigerated trucks is mainly used for fruits, seafood, milk and other perishable, perishable, easy fermentation long-distance transportation of goods.

Technical Specifications:


Product name
refrigerated truck
Cargo box dimension(mm)
Chassis model
Overall dimension(mm)
Brand name
Gross weight(Kg)
Drive type
Curb weight(Kg)
Fuel type
Axle No.
Emission standard
Cab seats(person)
Approach/departure angle(°)
Tires No.
Axle load (Kg)
Tire specification
Front/rear hang(mm)
Max speed(km/h)
Front/Rear track(mm)
Steel spring number
Engine parameters
Engine model
Engine manufacturer
Displacement (ml)
Dongfeng chaoyang forward power co ., LTD
Chassis Description
1..Dongfeng 4x2 chassis,single row with left/right hand drive optional.
2.3.8m wheelbase,125HP Chaochai Engine,5-speed transmission, front brige 2.5T/ rear brige 5T, 7.5-16 tire.
3.Oil brake and Power steering.
Standard Equipment
1. Refrigerator box volume: 20m³, the length of box is 5.05m.The material of cargo body is 6cm glass fiber-reinforced plastic board in two sides and PU foam in the core.
2. Equipped with heat preservation box body(realed),provision cooling plant,double rear doors, lighting system,temperature recorder,Aluminum alloy profile package edge , door frames,stainless steel lock pieces of and etc.
3.The temperature of cargo body inside could be 0-18°C,the cold storage effect is very obvious.
Optional Equipment
We can make the refrigerator truck according to customer's requirements with the optional equipments below:
1. The material of cargo body is optional according of which kinds of goods the truck transport, with perfect heat preservation(such as:.color steel plate,glass fiber-reinforced plastic board,stainless steel, stainless steel and etc.)
2. The thickness of polyurethane material has 6cm or 8cm for your option.
3. We can open side doors for the truck.The QTY of side door can be opened as per your requests.
4. Refrigerating unit: the international famous brand, such as USA "Carrier", "Thermo King" , Korea “ Hanya” ,refrigerating units made inChina and etc. .
5. Independent or un-independent refrigeration units.
6.The temperature of the cargo body inside could be 0-18°C for different goods.
7. 220V/380V electricity system for different requirements.
8. For the special requirements of trucks,such as the meat transportation, the meat hook, aluminum alloy guide rail and ventilation slots etc.
Please advise us in advance if you have any special requests for the refrigerator truck, we can equip various kinds optional equipment for you.
Refrigerator truck can transport frozen foods which are ice, dairy,fresh fruits and vegetables, vaccine,drug transporter, frozen goods and etc.
Product advantage
1. The advantages of refrigerator truck is simple structure, convenient operation and maintenance, low investment, cold storage quantity is relatively large, easy to control pollution to the environment.
2. Best Quality with competitive price.


Insulated truck body Main Characters:


Light in weight: 40% lighter than metal body.
Better insulation: K value less than 0.3w/m2k.
High in strength and long life: 5 times longer than metal body.
Non-corrosion, non-pollution, anti-brine, acid and soda-resisting.
Easy to assembly and repair at site.
