Sanitation Truck
Created with Pixso. ISUZU GIGA 6X4 20CBM Hydraulic Hook Arm Truck with Interchangeable Garbage Bins
Detail Information
Place of Origin:
China
Certification:
CCC/ISO
Drive Type:
6x4
Drive Model:
LHD, RHD
Material:
Q235 Carbon Steel
Loading Capacity:
20ton
Thickness:
Side--4mm, Bottom--5mm
Color And Logo:
Optional
Packaging Details:
Naked
Supply Ability:
500 units/month
Highlight:

ISUZU GIGA hook arm truck

,

20CBM hook lift garbage truck

,

interchangeable garbage bins hook truck

Product Description

A hook lift garbage truck adopts a hydraulic hook arm mechanism that allows quick loading and unloading of garbage containers without additional lifting equipment. It offers high working efficiency, flexible operation, and low operating costs, making it ideal for municipal sanitation departments, construction sites, factories, and waste transfer stations.


The ISUZU 6x4 20-ton hook lift garbage truck features a powerful hydraulic hook arm system, strong loading capacity, and reliable chassis performance. It can quickly load and unload large garbage containers without additional lifting equipment, improving operational efficiency and reducing labor costs. It is suitable for municipal waste management, construction projects, and industrial sanitation operations.


Truck Specification
Product Name ISUZU GIGA 6X4 20CBM Hydraulic Hook Arm Truck with Interchangeable Garbage Bins
Truck Manufacturer CLW GROUP
Overall dimensions (L×W×H) About 11225x2545x3940mm
Chassis Specification
Cabin ISUZU GIGA,LHD, A/C
Drive type 6*4
Wheelbase 4600+1370m
Fuel type of engine Diesel
Maximum horse power of engine 380hp
Number of cylinders of engine 6
Emission standard of engine Euro 6
Gear box type 10 forward &2 rear
Tyres Size 12R22.5
Quantity of tyres  10+1 spare tire
Upper Body specification
Loading Capacity 20ton
Material Q235 Carbon steel
Function Garbage containers bins size: 6000x2400x1800mm
Thickness: side--4mm, bottom--5mm
Hook box time ≤45s
The unloading time ≤50s
Color and logo can be optional

I Feature

ISUZU GIGA 6X4 20CBM Hydraulic Hook Arm Truck with Interchangeable Garbage Bins

  • Hydraulic Hook Arm System. Equipped with a hydraulic hook arm that loads and unloads detachable containers directly onto and off the truck chassis.
  • Detachable Waste Container Design. The truck works with removable containers of different sizes and designs to suit various waste collection requirements.
  • Flexible Container Options. Open-top, covered, and other compatible containers can be selected according to the type of waste being collected.
  • Hydraulic Control System. The lifting and loading operations are controlled by a hydraulic system, with operating controls and safety locks configured according to the vehicle design.
  • Customizable Specifications. Container dimensions, rated lifting capacity, chassis specifications, and other configurations can be selected to meet project requirements and local operating conditions.


I Advantage

  • One Truck Can Serve Multiple Collection Points. With several compatible containers available, the truck can exchange full containers for empty ones without waiting for each collection point to finish filling its container.
  • Less Manual Handling. The hydraulic hook arm handles the main loading and unloading work, reducing the need for workers to manually move heavy waste containers.
  • More Flexible Waste Collection. Containers can remain at construction sites, factories, residential areas, or municipal collection points until they are ready for collection.
  • Suitable for Different Types of Waste. With the appropriate container, the truck can transport household waste, construction debris, industrial waste, and recyclable materials.
  • Easier Waste Collection Scheduling. Detachable containers allow operators to arrange collection according to waste volume and site requirements, which is useful for locations where waste generation varies throughout the day.
