ISUZU 2.4 Meters 5.8 Meters Height Airport Ground Support Stair Vehicle

Brand Name:	ISUZU
Model Number:	CLWDT2026104
MOQ:	1 unit
Price:	$25000~$45000 /unit
Delivery Time:	35~45 working days
Payment Terms:	L/C,T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CCC / ISO901 / GCC

Condition:

100% New

Driving Type:

4x2, LHD, RHD

Engine:

Diesel Type

Maximum Tilt Angle:

38°

Working Height:

2400～5800 Mm

Height Adjustment Method:

Telescopic Upper And Lower Ladder Bodies

Packaging Details:

Naked

Supply Ability:

500 units/month

Highlight:

ISUZU Airport Ground Support

5.8 Meters Airport Stair Vehicle

2.4 Meters Airport Stair Vehicle

Product Description

An Aircraft Passenger Stair Truck (also known as an Airport Passenger Stairs Vehicle, Mobile Passenger Stairway, or Aircraft Boarding Stair Truck) is a specialized airport ground support vehicle designed to provide safe and efficient boarding and disembarking access between the ground and an aircraft when passenger boarding bridges are unavailable. The vehicle features an adjustable stair platform that can be raised or lowered to accommodate different aircraft door heights.

This aircraft passenger stair truck adopts ISUZU chassis, 5.8m height stair, Intelligent one-touch lift, dual lifting hydraulic cylinders, dual locking rack cylinders, aluminum profile footboard, LED lights, European and American brand hydraulic and components, safety interlocking and emergency unlocking system, intelligent management system, active anti-collision system, etc.

Truck Specification
Product Name	5.8M ISUZU Aircraft Passenger Stair Truck
Truck Manufacturer	CLW GROUP
Overall dimensions (L×W×H)	About 823025503700mm
Chassis Specification
Cabin	ISUZU
Drive type	4*2
Wheelbase	3800mm
Fuel type of engine	Diesel
Model of engine	4HK1
Maximum horse power of engine	190hp
Number of cylinders of engine	4
Emission standard of engine	Euro 2
Gear box type	5 forward &1 rear
Tyres Size	7.50R16
Quantity of tyres	6 +1 spare tire
Upper Body Specification
Capacity	5.8M ISUZU Aircraft Passenger Stair Truck
Maximum Tilt Angle of Ladder Body	38°
Passenger Ladder Working Height	2400～5800 mm
Step Dimensions	290×1490×190 mm
Number of Steps in Upper Ladder Body	14
Number of Steps in Lower Ladder Body	13
Height Adjustment Method	Telescopic upper and lower ladder bodies
Platform Dimensions	3350×1890 mm
Function	Equipped with intelligent one-touch lift
	Equipped with dual lifting hydraulic cylinders
	Equipped with dual locking rack cylinders
	Equipped with aluminum profile footboard
	Equipped with LED lights
	Equipped with safety interlocking and emergency unlocking system
	Equipped with active anti-collision system
	Equipped with intelligent management system
	Equipped with European and American brand hydraulic and components

I Feature

Adjustable Stair Height System

Equipped with a hydraulic or electro-hydraulic lifting mechanism that allows the stair platform to be adjusted for different aircraft door heights.

Wide Aircraft Compatibility

Suitable for servicing a variety of aircraft types, including regional jets, narrow-body aircraft, wide-body aircraft, mi-litary aircraft, and private jets.

Self-Propelled or Towable Design

Available as self-propelled units or towable passenger stairs to meet different airport operational requirements.

Safe Passenger Access

Designed with anti-slip stair surfaces, handrails, safety barriers, and platform protection systems to ensure passenger safety.

Stable Operating Platform

Features a robust chassis and stabilization systems that provide secure positioning during boarding and disembarkation operations.

Efficient Airport Ground Handling

Enables fast passenger boarding and deplaning, improving aircraft turnaround times and airport operational efficiency.

User-Friendly Control System

Equipped with simple and reliable controls for precise height adjustment and vehicle positioning.

Durable and Weather-Resistant Construction

Manufactured with high-strength materials and corrosion-resistant components for long-term outdoor operation.

Low Maintenance Requirements

Designed for reliable performance with durable hydraulic, electrical, and mechanical systems.

Customizable Configurations

Available in different height ranges, chassis options, stair widths, and airport-specific configurations to accommodate various aircraft and operational needs.

I Advantage

Improved Passenger Boarding Efficiency

Provides fast and convenient access to aircraft, helping reduce boarding and disembarkation times.

Wide Aircraft Compatibility

Adjustable height systems allow the vehicle to service regional aircraft, narrow-body aircraft, wide-body aircraft, business jets, and mi-litary aircraft.

Enhanced Airport Operational Efficiency

Supports quick aircraft turnaround, improving overall airport and ground handling productivity.

Safe Passenger Access

Equipped with anti-slip steps, handrails, safety barriers, and stable platforms to ensure passenger safety during boarding and deplaning.

Independent of Boarding Bridges

Enables passenger access at airports, remote stands, mi-litary bases, and temporary operating locations where jet bridges are unavailable.

Flexible Ground Support Solution

Can be easily deployed to different aircraft parking positions, providing greater operational flexibility.

Reliable and Stable Performance

Robust chassis design and advanced lifting systems ensure stable operation under various airport conditions.

Reduced Infrastructure Requirements

Eliminates the need for fixed passenger boarding bridges, making it a cost-effective solution for many airports and aviation operators.

Durable and Low-Maintenance Design

Built with corrosion-resistant materials and reliable hydraulic or electro-hydraulic systems for long service life.

Customizable for Different Airport Needs

Available in various height ranges, platform sizes, drive systems, and configurations to meet specific operational requirements.
