products details

Home Products

20m3 10MT LPG Storage Tank Skid Station with Dispensing System

Brand Name:	ASME
Model Number:	CLWDT26-118
MOQ:	1 UNIT
Price:	$25000-$35000/unit
Delivery Time:	35-45 working days
Payment Terms:	L/C,T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CCC/ISO

Tank Material:

Carbon Steel Q345R

Tank Capacity:

20M3 / 20000Liters /20CBM

Thickness Of Shell:

10mm

Thickness Of End Plate:

12mm

Design Pressure:

1.77 MPa

Logo And Color:

Optional

Packaging Details:

Naked

Supply Ability:

500 units/month

Highlight:

20m3 LPG Skid Station

Dispensing LPG Skid Station

Product Description

An LPG skid-mounted station is a compact integrated LPG supply system designed for LPG storage, transportation, dispensing, and gas filling operations. It usually consists of an LPG storage tank, LPG pump, flow meter, dispenser, piping system, safety valves, control system, and other safety accessories, all mounted on a skid base for convenient transportation and installation.

The LPG skid-mounted station is widely used for small and medium-sized LPG stations, residential gas supply, industrial fuel supply, mobile energy projects, and remote area gas distribution. Compared with traditional LPG stations, it offers advantages such as compact structure, fast installation, lower construction cost, flexible relocation, and convenient operation.

A 20 CBM LPG skid-mounted station is an integrated LPG storage and dispensing system designed for the storage, transfer, and refueling of liquefied petroleum gas (LPG), such as propane and butane. The station is equipped with a 20 cubic meter LPG storage tank, LPG pump, flow meter system, LPG dispenser, piping system, control system, and complete safety protection devices, all mounted on a skid base for convenient transportation and quick installation.

LPG Skid Station Specification
Product Name	20m3 10MT LPG Storage Tank Skid Station with Dispensing System
Tank Manufacturer	CLW GROUP
Overall Wimensions (L×W×H)	About 810018202410mm
Design Pressure	1.77 MPa
Filling Weight	10000kg
Tank Weight	2950kg
Thickness of shell	10mm
Thickness of end plate	12mm
Tank Capacity	20M3 / 20000Liters /20CBM lpg tank
Tank Material	Carbon steel Q345R
Tank diameter	1800mm
Accessories	Adapt 220V electricity to 380V with speed control
	LPG Filling Pump,2" inlet& outlet, 5.5KW, 380V/50Hz, Ex-proof,
	Pressure Gauge
	Level Gauge
	Temperature Gauge
	LPG Cylinder Filling Scale

I Feature

20m3 10MT LPG Storage Tank Skid Station with Dispensing System 0

Integrated design combining LPG storage, dispensing, pumping, and control systems in one compact unit.
Compact structure with skid-mounted design allows convenient transportation, quick installation, and easy relocation.
Equipped with high-quality LPG storage tank manufactured according to international pressure vessel standards for safe and reliable operation.
Advanced LPG pump and flow meter system provides accurate gas measurement and efficient dispensing performance.
Short installation period and simple foundation requirements help customers start operation quickly.

I Advantage

Integrated skid-mounted design combines LPG storage, pumping, dispensing, and control systems into one unit, greatly improving installation efficiency and operational convenience.
Lower investment cost compared with traditional LPG stations, reducing civil construction expenses, installation time, and overall project budget.
Fast installation and easy relocation make it ideal for temporary projects, remote areas, and markets requiring flexible LPG supply solutions.
Excellent sealing performance effectively reduces LPG leakage risk and improves environmental and operational safety.
High-quality pressure vessel tank manufactured according to international safety standards provides reliable performance, excellent pressure resistance, and long service life.
