60 Ton - 100 Ton Lowboy Trailer, Low Bed Semi Trailer 2 As / 3 As / 4 As
60 Ton - 100 Ton Lowboy Trailer, Low Bed Semi Trailer 2 As / 3 As / 4 As
Properti Dasar
Sertifikat
CCC; ISO9001
Model Produk
CSCLOW
Properti Perdagangan
MOQ
1
Patokan harga
could be negotiated
sedang mengemas
Telanjang atau Wax sebelum pengiriman
jangka waktu pengiriman
25 - 30 hari setelah menerima setoran
Metode Pembayaran
L/C, T/T, Western Union, MoneyGram
Kapasitas Pasokan
1000 per tahun
Detail Produk
Menyoroti:
flatbed semi trailer
,kontainer semi trailer
NO. Of Axle:
2 gandar, 3 gandar 4 gandar
Axle Brand:
FUWA, BPW, L1, HJ dll untuk opsional
Loading Capacity:
40 ton; 50 ton, 60 ton 80 ton, 100 ton
Suspension:
Suspensi mekanis; atau suspensi udara
King Pin:
JOST Brand 50 # atau 90 #
Name:
3 gandar trailer lowboy
Ringkasan produk
Tri-axle 3 Axle 60 ton - 100 ton Lowbed Trailer Low Loader Lowboy Lowbed Trailer Semi Berat Tare 12000kg Panjang keseluruhan 13000mm Lebar Keseluruhan 2500 + 250 * 2mm Muatan 60000-80000kgs Panjang dek kerja: 8000mm Ketinggian dek kerja: 700 mm Foto untuk referensi. Produk akhir dapat dibuat sesuai ...
Deskripsi Produk
Tri-axle 3 Axle 60 ton - 100 ton Lowbed Trailer Low Loader Lowboy Lowbed Trailer Semi
| Berat Tare | 12000kg |
| Panjang keseluruhan | 13000mm |
| Lebar Keseluruhan | 2500 + 250 * 2mm |
| Muatan | 60000-80000kgs |
| Panjang dek kerja: | 8000mm |
| Ketinggian dek kerja: | 700 mm |
| Foto untuk referensi. Produk akhir dapat dibuat sesuai dengan persyaratan yang tepat | ||
| SPESIFIKASI | ||
| I Beam & Chassis | Tugas berat dan daya tahan ekstra yang dirancang saya pancarkan; Memilih baja high tensile Q345B, dilas oleh proses-proses Submerged-Arc otomatis. Top Flange 20mm, lebar 140mm; Flange Tengah 14mm, Tinggi 500mm, Flange Bawah 20mm, lebar 140mm. | |
| Gandar | 3 gandar | |
| Penangguhan | Merek FUWA 13Tons | |
| Lantai | Pelat checker 5mm | |
| Daun musim semi | 10 buah Daun musim semi | |
| King Pin | JOST merek 2 ”Pin King Bolt-in | |
| Landing Gear | JOST merek Dua-kecepatan, operasi manual, alat pendaratan tugas berat | |
| Pelek Roda | Velg roda 7,5-20, 13 buah termasuk satu cadangan | |
| Ban | 10.00R20, 13 buah termasuk satu cadangan | |
| Lereng | Teknik ramp dengan pegas | |
| Ban serap | Satu set ban serep termasuk carrier | |
| Sistem pengereman | Katup relay WABCO RE 6; Ruang rem T30 / 30 + T30 Spring; Tangki udara 45L | |
| Lukisan | Pelap pasir Chassis lengkap untuk membersihkan karat, 1 lapisan anti korosi korosif, 2 lapis cat akhir | |
| Aksesoris | Satu kotak alat standar | |
Detail Kemasan
Lowbed 60-Ton Trailer Lowboy:
1. Packing Nude 3 set ditumpuk (oleh Kapal Cargo Massal, Ro-ro Ship, atau Transportasi Darat);
2. Potong bagian belakang yang dapat memuat dua set dalam satu kontainer 40ft;
3. Simpan trailer asli tetapi muat dua set dalam satu kontainer 45ft.
Dua / Tiga Unit Menaruh satu paket untuk Tri-gandar 3 Gandar 60 ton - 100 ton Lowbed Trailer Low Loader Lowboy Lowbed Trailer Semi.
